Smart Module FC100

100kVA - 4MVA

Modular Static Frequency Converter

Modular, Clean and Efficient Frequency Conversion

The Smart MODULE FC100 is highly configurable modular static frequency converter constructed using power modules for best redundancy. 100kVA Power modules operate as rectifiers to source sinusoidal current from the supply, and inverters to reproduce the AC waveforms on the output . For operation of the power modules an isolation transformer is applied to the input or output the as part of the Smart MODULE FC100 system.


Typical FC100 Applications are Interconnection of ships at berth to the grid (Shore-to-ship ),On-board vessels (shore power converter) and special industrial applications such as floating platform storage and offloading operations for the oil and gas industry


 Modular SFC with independent rectifier and inverter modules
 Non-Stop operation with excellent Master-Slave Control
 Fully isolated AC connection using an output transformer
 Seamless generator change over
 Parallel load sharing
 Minimum spare part required
 Wide range of voltages available; 50 Hz and 60 Hz

Request Offer Find Distributor


Highlights



Stable Voltage & Frequency
Clean, full sine-wave output at the new frequency and voltage.


Modular Redundancy
Seamless load transfer to other modules in fault case.


Easy Maintenance
Small footprint and front access for easy service.

FEATURES

Maximum Power Availability with Redundancy

State-of-the-art IGBT technology with DSP control

Modular Design with independent rectifier and inverter modules.

Bi-directional power flow

Non-Stop operation with excellent Master-Slave Control

Scalable up to 4MVA



Advanced Power Conversion System (PCS) Technology

50Hz/60Hz Frequency Conversion Mode High overall efficiency 96%

Maximum Power (PF 0,9 and PF 1 for kW=kVA)

Input Power Factor Correction (PFC) ECO Mode for Energy Savings

Power-On Self Test

Managing All Modules via Single Screen



Compact Design with High Power Density

All front access serviceability

Lowest Mean Time To Repair 15 min.

Minimum spare part requirement

No moving elements

MODEL SmartModule 300 kVA
Capacity 300 kVA
Power Watt 270 kW
INPUT
Voltage 400VAC -15% +10% 3P+PE
Frequency Range 30-70 Hz
Power Factor At 100% Load >0,99
Total Harmonic Distortion (THDi) <4%
OUTPUT
Power Factor 0.9
Voltage 400 VAC
Recovery At 0% - 100% - 0% Load Output Tolerance up to 5%, Return to 1% Band <40ms.
Voltage Tolerance ±1% Static, ±3% Dynamic
Frequency Range 50-60 Hz ±0,5% (Selectable)
THD Linear Load <2% / Non-Linear Load <6%
Crest Factor 3:1
Overload At 125% Load 10min, at 150% Load 1min
Efficiency Up to 95%
Protections Input voltage and frequency out of tolerances, phase interruption at the input, output voltage and frequency out of tolerances, phase interruption at the output, DC component that may occur in the output voltage, Overload that will occur at the output (outside the specified times), heating at a leve
ENVIRONMENTAL
Operation Temperature 0°C~+40°C
Storage Temperature -15°C~+40°C
Protection Class IP20
Chassis Electro-Static Paint Protected
Humidity 0-95%
Altitude Power Correction Factor: PF 1: 0 – 1000 mt, PF 0,92: 1000 – 2000 mt, PF 0,84: 2000 - 3000 mt
Event Log 1500 Detailed Events (Status Menu Saved)
Paralelleling Up to 8 Parallel Power Boosts
EPO (Emergency Power Off) Standard
Isolation Transformer Optional
Weight (kg) 1100
COMMUNICATION
Communication Port RS232 Standard, RS485 and SNMP Adaptor Option
Dry Contact Optional
Protocol SEC, TELNET
STANDARDS
Quality ISO 9001
LVD / Safety IEC/EN62040-1, IEC/EN60950-1
EMC EN 62040-2
DIMENSIONS &WEIGHT
Cabinet Dimensions (mm) (WxDxH) 911x810x2010
Net Weight (kg) 623

Gallery  MARINE SHORE POWER CONVERTER
