Smart TP
10 - 800 kVA
Online UPS
Three Phase Industrial UPS with built in Transformer
High Protection with Built In Isolation Transformer
High Reliability with Full DSP Control
Strong Overload Capability
LBS Synchronization
Highlights
High Performance
Smart TP Series is a true VFI on-line double conversion, three-phase UPS system and engineered to provide high level reliable and robust protection for most demanding industrial and medical environments.DSP Technology and Inverter Transformer makes Smart TP Series one of the most reliable systems for data security and other critical applications.Compact design with an Integrated transformer on the inverter output ensuring galvanic isolation on the output for ultimate safe installation.
Lowest Total Cost of Ownership
IGBT based power factor correction technology provides input power factor close to 1 (≥ 0,99). The high input power leads to reduced electricity pay-out, minimizes cable, switchboard, fuse and generator requirements, thus reducing investment cost. Intelligent battery management system and advanced battery auto float/boost charge technology, reduces the frequency of battery maintenance, greatly improves the battery efficiency and extends battery life.
Maximum Availability
Parallel configuration up to 6 units per redundancy (N+X) and power increase. Non-fixed Master-Slave relationship: Among several UPS in parallel, the unit startup first is Master UPS, the others are Slave. The master and slave may be exchanged. LBS synchronization: Synchronize the output of the two independent UPS systems (single unit or parallel) even when the two systems are operating on different modes (bypass/inverter) or on battery.
Flexibility
Flexible battery configuration ranging from 360-408VDC/480VDC. Optional IP31, IP41, Protection degree for harsh environments. Optional temperature sensor for external battery cabinets for extended runtimes. External battery cabinets for different sizes of batteries to provide extended runtimes. Adaptability to the mains without neutral.
FEATURES
High Performance
-
Smart TP Series is a true VFI on-line double conversion, three-phase UPS system and engineered to provide high level reliable and robust protection for most demanding industrial and medical environments.
DSP Technology and Inverter Transformer makes Smart TP Series one of the most reliable systems for data security and other critical applications.
Compact design with an Integrated transformer on the inverter output ensuring galvanic isolation on the output for ultimate safe installation.
Lowest Total Cost of Ownership
-
IGBT based power factor correction technology provides input power factor close to 1 (≥ 0,99).
The high input power leads to reduced electricity pay-out, minimizes cable, switchboard, fuse and generator requirements, thus reducing investment cost.
Intelligent battery management system and advanced battery auto float/boost charge technology, reduces the frequency of battery maintenance, greatly improves the battery efficiency and extends battery life.
Maximum Availability
-
Parallel configuration up to 6 units per redundancy (N+X) and power increase.
Non-fixed Master-Slave relationship: Among several UPS in parallel, the unit startup first is Master UPS, the others are Slave. The master and slave may be exchanged.
LBS synchronization: Synchronize the output of the two independent UPS systems (single unit or parallel) even when the two systems are operating on different modes (bypass/inverter) or on battery.
Flexibility
-
Flexible battery configuration ranging from 360-408VDC /480VDC.
Optional IP31, IP41, Protection degree for harsh environments.
Optional temperature sensor for external battery cabinets for extended runtimes.
External battery cabinets for different sizes of batteries to provide extended runtimes. Adaptability to the mains without neutral.
| MODEL | Smart TP 10 kVA |
|---|---|
| Capacity | 10kVA kVA |
| Power Watt | 9kW kW |
| INPUT | |
| Operating Voltage Range | 380/400/415 VAC (-25% / +20%), 3Ph+N+PE) |
| Operating Frequency Range | 50/60Hz (±5HZ) |
| Power Factor | >0.97 (With Filter) |
| OUTPUT | |
| Output Voltage | 380/400/415 VAC (±1%) |
| Output Frequency | 50/60Hz (±5HZ) |
| Harmonic Distortion (THD) | <3% (Linear Load) |
| Crest Factor | 3:1 (Max) |
| Efficiency | ≥88% |
| BYPASS | |
| Rated Voltage | 380/400/415 VAC |
| Rated Frequency | 50/60Hz |
| Voltage Protection Range | Upper Limit: +20% (+10%, +15%, +20% Adjustable); Lower Limit: -40% (-10%, -20%, -30%, -40% Adjustable) |
| Frequency Protection Range | ±10% (±2.5%, ±5%, ±10%, ±20% Adjustable) |
| BATTERY | |
| Voltage Range | 384 VDC (360-384 VDC) |
| SYSTEM FEATURES | |
| Transfer Time | 0ms (Line Mode ‹—› Battery Mode) |
| Rated Frequency | 110%/60min, 125%/10min, 150%/1min |
| LED Display | Input, Inverter, Bypass, Battery, Output, Status |
| LCD Display | I/O Voltage, Frequency, Power, Power Factor, Battery Voltage, Current, Battery Status, Load Percentage, UPS Status, History Record |
| Communication Interface | Dry Contact, RS 232, Rs485, SNMP Card (Optional) |
| Optional | Harmonic Filter, SNMP Adapter, LBS Cables, Battery Temperature Sensor, Bypass Current - Sharing Inductor |
| ENVIRONMENTAL | |
| Operating Temperature | 0°C ~ 40ºC |
| Storage Temperature | -25ºC ~ 55ºC |
| Humidity Range | 0 ~ 95% (Non-Condensing) |
| Altitude | <1500m |
| Noise Level | <60dB |
| DIMENSIONS &WEIGHT | |
| Dimensions WxDxH (mm) | 570 x 800 x 1195 mm |
| Weight (kg) | 217 kg |
| Shipping Weight (kg) | 272 kg |
| STANDARDS | |
| Safety | IEC/EN62040-1; IEC/EN60950-1 |
| EMC | IEC/EN62040-2, IEC61000-4, IEC61000-4-3; IEC61000-4-4; IEC61000-4-5; IEC61000-4-6; IEC61000-4-8 |
